Deep Drawing Steel Plate DC06
China Ultra deep drawing steel plate DC06 the preferred material for high ductility precision stamping
Direct supply in stock | Super formability | Smooth surface | Suitable for complex stamping parts
GNEE STEEL specialize in supplying ultra deep drawing grade cold-rolled steel plate DC06, which has extremely high elongation and excellent deep drawing performance. It is designed specifically for difficult stamping forming and widely used in industries such as automobiles, home appliances, electronics, etc. It is an ideal choice for complex precision components!
- Core application areas of DC06 ultra deep drawing steel plate
1. In the field of automobile manufacturing
Body coverings: door inner panels, engine hood, trunk lid, etc., requiring high formability and smooth surface.
Oil tank and oil pan: deep drawn without cracks, ensuring sealing and safety.
Interior parts: dashboard brackets, seat components, etc., suitable for complex curved surface designs.
2. Home appliance industry
Refrigerator/washing machine panel: High surface quality, beautiful and durable.
Air conditioner casing and heat sink: do not deform after deep drawing, ensuring assembly accuracy.
Kitchen appliances (such as range hoods and microwave ovens): both high strength and formability.
3. Electronics and Precision Hardware
Battery case: phone and laptop battery case, lightweight and stamped without damage.
Precision connectors/shielding covers: high dimensional stability, suitable for stamping small parts.
Lamp accessories: reflector cover, lamp holder, etc., with a smooth and flawless surface after molding.
DC06 Core Advantages
✅ Ultra deep drawing performance: elongation rate ≥ 38%, far exceeding ordinary cold-rolled plates (such as DC01/DC03), suitable for extreme stretching forming.
✅ High surface quality: FB (premium finishing surface), can be directly sprayed or electroplated, eliminating the need for secondary treatment.
✅ Low yield strength: easy to form, reduces mold wear, and lowers production costs.
✅ Uniform material: pure composition (low carbon, low sulfur and phosphorus), no risk of cracking or wrinkling during stamping.
| Parameter | Specification |
| Length | – Sheet: 1000–6000 mm (custom) – Coil: Coil diameter Φ800–Φ2500 mm (by weight) |
| Thickness | 0.35–3.0 mm |
| Width | 700–1850 mm |
| Standard | – EU: EN 10130-2006, EN 10152-2017 – China: GB/T 5213-2019 |
| Process | – Cold rolling + Continuous annealing + Skin-pass – Optional: Galvanizing (Electrolytic ZE/Hot-dip GI) |
| Surface Treatment | Base grade (EN 10152): – FB (Standard) – FC (Improved) – FD (Advanced) Coating/Finish: – Bare (Oiled O) – Galvanized (ZE50/GI60) + Combined (P/C/O) |
| Thickness Tolerance | Coil (EN 10140): – ≤0.7 mm: ±0.03 mm – 0.7–1.5 mm: ±0.04 mm – >1.5 mm: ±0.05 mm Sheet (GB/T 708): ±0.02–0.05 mm (grade-dependent) |
Comparison between DC06 and other stamping materials
Grade: Tensile Strength (MPa), Elongation (%), Typical Applications
DC06 270-350 ≥ 38% high difficulty deep drawing parts (fuel tank, precision shell)
DC04 270-350 ≥ 34% general stamping parts (home appliance panels)
DC03 270-370 ≥ 30% simple bending parts (brackets, structural parts)
DC01 270-410 ≥ 28% basic molded parts (low requirement parts
Why choose us?
- Adequate inventory: Regular thickness of 0.5-3.0mm available in stock, supporting customization.
- Technical support: Provide material selection and stamping process optimization support.
- Quality certification: Complies with international standards such as EN 10130 and JIS G 3141, ensuring reliable quality assurance.
- Consult now! Let DC06 bring higher molding qualification rates and lower production costs to your products!
