Galvanized Steel Plate





Galvanized Steel Plate is mild steel with a coating of zinc. The zinc protects the steel by providing cathodic protection to the exposed steel, so should the surface be damaged the zinc will corrode in preference to the steel. Zinc steel is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion.



Product Parameters



GALVANIZED SHEET SPECIFICATIONS

Product Name

Galvanized Steel Sheet

Technical Standard

EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653

Steel Grade

Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQCR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer's Requirement

Type

Coil/Sheet/Plate/Strip

Thickness

0.09-6.00mm,or Customer's Requirement

Width

600mm-1500mm, According to Customer's Requirement

Type of Coating

Hot Dipped Galvanized Steel(HDGI)

Zinc Coating

30-275g/m2

Surface Treatment

Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)

Surface Structure

Normal Spangle Coating(NS), Minimized Spangle Coating(MS), Spangle-Free(FS)

Quality

Approved by SGS,ISO

Plate Weight

3-20 Metric Tons

Package

Water Proof Paper Is Inner Packing,Galvanized Steel Or Coated Steel Sheet Is Outer Packing , Side Guard Plate,Then Wrapped Byseven Steel Belt.Or According To Customer'S Requirement

We support customization of color-coated coils of various specifications and uses



Usage

Grade

Yield Strength (MPA)

Tensile Strength (MPA)

Elongation rate %

Punching galvanized steel

DX51D+Z

~

270-500

>=20

DX52D+Z

140-300

270-420

>=22

DX53D+Z

140-260

270-380

>=26

DX54D+Z

140-220

270-350

>=30

Structure galvanized steel

S220GD+Z

>=220

>=300

>=18

S250GD+Z

>=250

>=330

>=17

S280GD+Z

>=280

>=360

>=16

S320GD+Z

>=320

>=390

>=15

S350GD+Z

>=350

>=420

>=14

S400GD+Z

>=400

>=470

~

S500GD+Z

>=500

>=530

~

S550GD+Z

>=550

>=560

~



Standard and grade

National standard



Comparable to foreign standards



Function and use

Material category

Executive standard

Grade

Standard

Grade

Suitable for the manufacture of cold-formed parts


Mild Steel Coil

Q/BQB302

SPHC

JISG3131

SPHC

SPHD

SPHD

SPHE

SPHE

SAE1006/SAE1008



SAE1006/SAE1008

XG180IF/200IF

XG180IF/200IF

General structural steel

GB/T912-1989

Q195

JISG3101

SS330

For general construction of buildings, bridges, ships, vehicles, etc.

Q235B

SS400

SS400

SS490

ASTMA36

SS540



Characteristics of Galvanized Steel Plate



01


Wide Usage and Long Anti-Corrosion Life

Galvanized steel plates are widely used in various environments, offering long-lasting corrosion resistance. The anti-corrosion lifespan varies depending on the specific environment.


02


Low Processing Cost

The cost of corrosion protection for galvanized steel plates is lower compared to other paint coatings.


03


Durability in Suburban Environments

The standard galvanized anti-corrosion coating requires no maintenance and can last for over 50 years, especially in suburban environments.

Q235 Galvanized Steel Plate



Q235 Galvanized Steel Plate



Galvanized steel plate inspection

1. Size and shape measurement items: Allowable deviation of thickness, width, length, unevenness, out of square degree and sickle bend.

2. Chemical composition test items: Carbon content, sulfur content, manganese content, silicon content, phosphorus content, titanium content, aluminum content, niobium content, vanadium content, etc.

3. Physical performance test items: Yield strength, tensile strength, elongation after breaking, R value, N value, tensile strain mark, baking hardening value, coating adhesion, coating weight, coating surface structure, surface quality, adhesion and corrosion resistance.

4. Environmental performance evaluation test items: Lead content, content, cadmium content and hexavalent chromium content.

5. Galvanized sheet brand identification



Application Fields






Construction Engineering

Used in industrial plant enclosure systems and warehouse logistics roof slabs.




Automobile Manufacturing

Side panels for truck compartments and protective layers for new energy battery packs.




Home Appliance Industry

Stamping substrate for air conditioning outer casings and washing machine inner drums.




Agricultural Facilities

Roofs for livestock breeding sheds and skeletons for greenhouses.




Municipal Engineering

Road noise barriers and underground pipe gallery ventilation systems.




Home Decoration

Metal ceiling panels and custom furniture frames.




Packaging and Transportation

Protective covers for large equipment and moisture-proof liners for export goods.




Energy Equipment

Photovoltaic support substrates and grounding grids for power transmission and transformation facilities.



Packaging & Shipping





Packing Details

Export standard package,bundled or be required.

The inner size of container is below:
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)

Delivery Details

7-15 dyas,or according to the order quantity or upon negotiation



Certificates



productcate-1-1



FAQ



Q: Will you delivery the goods on time?

A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.

Q: Do you provide samples ? is it free or extra ?

A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.

Q: Do you accept the third party inspection?

A: Yes absolutely we accept.

Q: How could you guarantee your products?

A: Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
