Grade S320GD is a structural steel with a yield strength of at least 320 MPa.S320GD is available in the following hot dip coatings: S320GD+Z (galvanized), S320GD+ZF (galvanized-iron), S320GD+ZA (galvanized-aluminum), S320GD+AZ (aluminum-zinc), S320GD+AS (galvanized-iron) aluminum silicon).
The thickness of the zinc layer is one of the important factors affecting corrosion resistance. The thicker the zinc layer, the better the corrosion resistance. Generally, the zinc layer thickness of hot-dip galvanized steel sheets is above 30g/m2, even up to 600g/m2, and the zinc layer thickness of S320GD Z275 grade is 275g/m2.
GNEE Steel produces and tests S320GD Z275 galvanized steel coils in strict accordance with EN 10346 standards, ensuring that each batch of products meets customer requirements.
Product Introduction: S320GD Galvanised Steel Coil
| Name | S320GD Z275 Galvanized Steel Coil |
| Thickness | 0.12-5mm |
| Standard | AiSi,ASTM,bs,DIN,JIS,GB |
| Width | 12-1500mm |
| Grade | S320GD |
| Coating | Z40-Z275 |
| Technique | Coled Rolled Based |
| Coil Weight | 3-8 Tons |
| Spangle | Zero.minimum .Regular Big Spangle |
Chemical Composition Of S320GD (Casting Analysis)
| Designation | Chemical composition % by mass max. |
||||||
| Steel grade | Symbols for the types of available coatings | C | Si | Mn | P | S | |
| Steel name | Steel number | ||||||
| S320GD | 1.0250 | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 0,20 | 0,60 | 1,70 | 0,10 | 0,045 |
Mechanical Properties Of S320GD (Longitudinal)
| Designation | Mechanical properties | ||||
| Steel grade | Symbols for the types of available coatings | Proof strength Rp0,2 a MPad min. |
Tensile strength Rm b MPad | Elongation A80 c % min. | |
| S320GD | 1.0250 | +Z,+ZF,+ZA,+ZM,+AZ,+AS | 320 | 390 | 17 |
S320GD steels
GNEE Gi Coil Product Packaging and Shipping
GNEE hot-selling product recommendations
Why choose GNEE STEEL?
200 employees.
2 hot-dip galvanized steel pipe production lines
2 galvanized coil production lines
1 colored steel coil production lines
1 hot-dip galvanized square and rectangular steel pipe production lines
3 nationally recognized laboratories
Sales and production exceeds 300,000 tons
We mainly produce galvanized coils, galvanised sheets, and galvanized steel tubes.
