What is the difference between DX51D and DC51D?
DX51D vs DC51D
DX51D uses the EN10327 standard, and DC51D uses the Q/BQB402 standard. DX51D uses the same level as DC01 when the base plate is cold-rolled, and the same level as DD11 when it is hot. DC51D substrate is DC01 cold rolled low carbon steel plate.
What is the difference between DX51D and DX52D?
DX51D and DX52D are both hot-dip galvanized steels used for cold forming. DX52D has higher ductility and better elongation than DX51D. DX52D is more suitable for complex forming processes that require greater flexibility, while DX51D is used for standard forming applications.
What is DX51D AZ150 material?
Dx51d AZ150 is a hot-dip aluminum-zinc steel alloy with a coating of 55 percent aluminum, 1.6 percent silicon, and 43.4 percent zinc. The chemical composition of Dx51d AZ150 offers superior resistance to heat and corrosion, with high thermal reflectivity and conductivity.
What is the yield strength of DC51D?
Relatively high strength: The yield strength of DC51D+Z steel is usually between 280-320 MPa, and its strength is relatively high.
What is the meaning of AZ150?
What does AZ150 mean? AZ150 means that in the triple spot test in the en 10346 standard, the minimum total coating mass on both surfaces of the aluminum-zinc alloy coating is 150g per square meter. Equivalent to Total Both Sides in ASTM a792 standard is 0.50 oz/square foot.
