Name: China Cold Rolled Steel Sheet ASTM A1008 Manufacturers Suppliers Factory - Good Price - Gnee Steel
Brand: GNEE
SKU: 282271935

ASTM A1008 Cold Rolled Steel

Cold Rolled Steel is a mill product made with a high degree of gauge accuracy and uniformity of physical characteristics. The smooth deoxidized matte finish gives an excellent base for paint, lacquer and enamel. Box annealing and absence of scale permit stamping and moderate drawing operations. Sheets bend flat on themselves without cracking. Oiling protects surface against rust.

Our Cold Rolled sheet and coil conform to ASTM A1008M.

Order Details

Product name	Colled Rolled Steel Sheet/Plate/Coil
Grade	DC01,DC03,DC04,DC05,SPCC,ST12,ST13,ST14,ST15,ST16etc
Surface	Bright,Matt
Processing Service	Bending,Welding,Decoiling,punching,Cutting
Thickness	0.30mm-3.0mm
Width	800mm-1500mm or asCustomerrequired
Standard	ASTM, GB, EN, BS, JIS, Etc
Usage	Automobile manufacturing, home appliances (washing machines, refrigerator shells), office furniture, computer chassis and cabinets, general stamping parts
PAYMENT TERMS :	1.100% irrevocable L/C at sight. 2.30% T/T prepaid and the balance against the copy of B/L. 3.30% T/T prepaid and the balance against L/C
Packing	1.Big OD:in bulk 2.Small OD:packed by steel strips 3.woven cloth with 7 slats 4.according to the requirements of customers
Delivery Time	Delivered within 3-7 days after the receipt of deposit

Contact Us Today For A Fast Quote And Expert Support.

Thickness & Width

10GA (.1405 MAX – .1265 MIN) *** 48 60

11GA (.1256 MAX – .1116 MIN) *** 48 60

12GA (.1106 MAX – .0966 MIN) *** 48 60

13GA (.0947 MAX – .0827 MIN) *** 48 60

14GA (.0797 MAX – .0677 MIN) 36 48 60

16GA (.0648 MAX – .0538 MIN) 36 48 60

18GA (.0518 MAX – .0428 MIN) 36 48 60

20GA (.0389 MAX – .0329 MIN) 36 48 60

22GA (.0329 MAX – .0269 MIN) *** 48 60

24GA (.0269 MAX – .0209 MIN) *** 48 ***

Cold Rolled Steel Sheet ASTM A1008

Cold Rolled Steel Specification

Thickness: 0.15-1.2mm

Width: 700-1250mm

Diameter: 6010mm

Diameter: 2000mm

Coil weight: 20T.

Grade: Q195A-Q235A, Q195AF-Q235AF, Q295A(B)-Q345A(B): SPCC, SPCD, SPCE, ST12-15 DCO1-06

Standard	Grade	Chemical Composition of Cold Rolled Mild Steel(%)					Mechanical propertiesofcoldrolledsteel
		C	Si	Mn	P	S	Yielding Strength (MPa)	Tensile Strength (MPa)	Elongation (%)
JISG3141	SPCC	0.15 max	-	0.60 max	0.10 max	0.05 max
	SPCD	0.12 max	-	0.50 max	0.04 max	0.04 max	≤ 240	≥ 270	≥ 41
	SPCE	0.10 max	-	0.45 max	0.03 max	0.03 max	≤ 220	≥ 270	≥ 43
	SPCF	0.08 max	-	0.45 max	0.03 max	0.03 max	≤ 210	≥ 270	≥ 45
JIS G3141 Surface quality classification: B-finish; D-mirror finish Heat treatment or state: A - annealed; S - tempered , 8 -1/8 hard, 4-1/4 hard, 2-1/2 hard, 1-hard
EN 10130	DC01	0.12 max	-	0.60 max	0.045 max	0.045 max	140-280	270-410	≥ 28
	DC03	0.10 max	-	0.45 max	0.035 max	0.035 max	140-240	270-370	≥ 34
	DC04	0.08 max	-	0.40 max	0.030 max	0.030 max	140-210	270-350	≥ 38
	DC05	0.06 max	-	0.35 max	0.025 max	0.025 max	140-180	270-330	≥ 40
	DC06	0.02 max	-	0.25 max	0.020 max	0.020 max	120-170	270-330	≥ 41
Surface type: A, B; Surface specification: b=special smooth, g=smooth, m=non-glossy, r=rude Example of plate naming: EN 10130+A1-DC03-B-g where B is the surface type and g indicates that the surface specification is smooth

Performance: Mainly used in low carbon steel grades, requires a good cold bending and welding performance, and some stamping performance.
Application: cold-rolled products with excellent mechanical and processing properties and thickness of theprecise characteristics are widely used in construction, automotive, transportation and other industries, and as a hot dip for raw materials.

Request a Free Quote Within 24 Hours.

Cold Rolled Steel Sheet ASTM A1008

Production Process

The sheets are not heated duing the process, so there are no pitting and skin defects such as iron oxide, but good-quality and smooth surface. And the accuracy of the cold-rolled products' size is high. The performance and organization of the product can meet some special requirements, such as the electromagnetic properties, deep drawing properties.

Rolling process speed: 1000m/min

Forms of energy: electricity, water, steam

Cold Rolled Steel Sheet ASTM A1008

GNEE STEEL's qualifications

GNEE STEEL Are Professional And International:

We have many experienced employees. Among those, some are professional staffs who have worked in the international steel field for over 20 years. With excellent team-work, we know well about how to handle iron and steel international business with professional service which has brought our continuous business growth and our customer's satisfaction from the beginning.

Cold Rolled Steel Sheet ASTM A1008
