They are intended for use in the oil and gas industry for their high strength. The first step in the production of an Api 5l Seamless Pipe is when raw steel is initially cast into a more workable starting form. Typically the form could be a hot billet for seamless and flat strip for a welded variety. After being cast the raw steel is then moulded into an Api 5l Line Pipe. This can be done by pulling or by stretching the hot steel billet out into a seamless formed pipe. The technical committee at the API created two distinct levels or PSL for different requirements. The standard variety of pipes were labelled as Api 5l Psl1.
| Sizes | Nominal Pipe Size 1/2" to 48 " O.D. Wall Thickness - Schedule 10 through 160, STD, XS, XXS. |
|---|---|
| Product Specification Level (PSL) | API 5L PSL 2 API 5L PSL 1 |
| Thickness | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Applications | Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes |
| Pipe End | Plain, Bevel, Screwed, Threaded |
| API 5L Pipes Type | Seamless / ERW / Welded / Fabricated / CDW |
| API Line Pipe Length | Single Random, Double Random & Required Length, Custom Size - 12 Meter lengths |
| Testing and Inspection Reports | EN 10204 3.1, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, Destructive Test Report, Non Destructive Test Reports, Mill TC EN 10204 3.1, NABL Approved Lab, Chemical and Mechanical Reports, India Boiler Regulations (IBR) Test Certificate |
| Packing | API 5L GR. B Pipe Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests |
| Finishes | Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap.End Finishes:Beveled, Square Cut, Threaded & Coupled. |
| Other manufacturers of API Seamless steel pipe | MSL, JSL, ISMT, USL, BAO, Lontrin, SMTM, TNRS, V&M and Wuxi |
| HS Code |
730410 Line pipe of a kind used for oil or gas pipelines: Of iron or nonalloy steel: 730420 Casing, tubing and drill pipe, of a kind used in drilling for oil or gas: Casing: 730431 Tubes, Pipes and Hollow Profiles, of Iron or Non-alloy Steel, Cold-drawn or cold-rolled (cold-reduced) 730439 Other Tubes, Pipes and Hollow Profiles, of Iron or Non-alloy Steel 730441 Tubes, Pipes and Hollow Profiles, of stainless steel , Cold-drawn or cold-rolled (cold reduced) 730449 Other Tubes, Pipes and Hollow Profiles, of Stainless Steel, Seamless 730451 Tubes, Pipes and Hollow Profiles, of Other Alloy Steel, Cold-drawn or cold-rolled (cold reduced) 730459 Other Tubes, Pipes and Hollow Profiles, of Other Alloy Steel, 730490 Other Tubes, Pipes and Hollow Profiles, Seamless, of Iron or Steel |
| BS EN 10208-2:2009 | Steel pipes for pipelines for combustible fluids. Technical delivery conditions. Pipes of requirement class B. Suitable to use in maximum operating pressure over 16 bar. |
| Test Methods |
Hydrostatic test Bend test Flattening test Guided-bend test CVN impact test for PSL2 pipe (including pipe body tests, pipe weld and HAZ tests) DWT test for PSL2 welded pipe |
