ASTM A209 Grade T1 Alloy-Steel Boiler and Superheater Tubes
Standard:ASTM A209/A209M
Standard Specification for Seamless Carbon-Molybdenum Alloy-Steel Boiler and Superheater Tubes
ASTM A209 Grade T1 Seamless Steel Tubes covers minimum-wall-thickness, seamless, carbon-molybdenum alloy-steel,boiler and superheater tubes.
ASTM A209 Grade T1 Seamless Carbon-Molybdenum Alloy-Steel Boiler and Superheater Tubes covers tubes 1 ⁄ 2 to 5 in. [12.7 to 127mm] inclusive, in outside diameter and 0.035 to 0.500 in. [0.9 to 12.7 mm], inclusive, in minimum wall thickness.
ASTM A209 Grade T1 Alloy-Steel Boiler and Superheater Tubes Quick Details
Manufacture:Seamless process ,Hot-finished or Cold-finished
Wall thickness(WT): 0.9 mm--12.7 mm.
Outer diameter (OD): 12.7 mm--127 mm
Length: 6M or specified length as required.
Ends: Plain End, Beveled End, Treaded
Additional Info
Port of Shipment: Tianjin, China
Payment Terms:T / T, LC
Delivery: 7-15 days after payment
Surface: Tubes will be varnished (Outside only) to prevent rust.
Marking: Standard + Steel Grade + Size + Heat No + Lot No
Package: Bundles (hexagonal),Wooden Boxes,Crates (steel/wooden) or as required
Materials and Manufacture
The steel shall be killed.
The tubes shall be made by the seamless process and shall be either hot-finished or cold-finished, as specified.
HeatTreatment
Hot-finished tubes shall be heat treated at a temperature of 1200 °F [650 °C] or higher.
Cold-finished tubes shall, after the final cold finishing, be heat treated at a temperature of 1200 °F [650 °C] or higher, or tubing may be furnished in the full-annealed, isothermal annealed, or normalized and tempered condition.
Chemical Composition Of ASTM A209 Grade T1
| Element | Composition, % |
| Grade T1 | |
| Carbon | 0.10–0.20 |
| Manganese | 0.30–0.80 |
| Phosphorus, max | 0.025 |
| Sulfur, max | 0.025 |
| Silicon | 0.10–0.50 |
| Molybdenum | 0.44–0.65 |
Mechanical Properties Of ASTM A209 Grade T1
| Grade T1 | |
| Tensile strength, min, ksi [MPa] | 55 [380] |
| Yield strength, min, ksi [MPa] | 30 [205] |
| Elongation in 2 in. or 50 mm, min, % | 30 |
| For longitudinal strip tests a deduction shall be made for each 1 ⁄ 32 -in. [0.8-mm] decrease in wall thickness below 5 ⁄ 1 6 in. [8 mm] from the basic minimum elongation of the following percentage | 1.50 A |
| When standard round 2-in. or 50-mm gage length or smaller proportionally sized specimen with the gage length equal to 4D (four times the diameter) is used | 22 |
| Brinell Hardness Number (Tubes 0.200 in. [5.1 mm] and over in Wall Thickness), HBW | 146 |
| Rockwell Hardness Number (Tubes less than 0.200 in. [5.1 mm] in Wall Thickness), HRB |
80 |
Tests
Tension Test-One tension test shall be made on a specimen for lots of not more than 50 tubes. Tension tests shall be made on specimens from two tubes for lots of more than 50 tubes
Flattening Test-One flattening test shall be made on specimens from each end ofone finished tube.
Flaring Test-One flaring test shall be made on specimens from each end ofone finished tube.
Hardness Test-Brinell or Rockwell hardness tests shall be made on specimens from two tubes from each lot.
The dimensional tolerances of ASTM A209 Alloy-Steel Boiler and Superheater Tubes
Tolerances of Wall Thickness
| Wall Thickness, % | ||||||||
| Outside Diameter in. [mm] |
0.095 [2.4] and Under | Over 0.095 to 0.150 [2.4 to 3.8], incl |
Over 0.150 to 0.0180 [3.8 to 4.6], incl |
Over 0.180 [4.6] | ||||
| Over | Under | Over | Under | Over | Under | Over | Under | |
| Seamless, Hot-Finished Tubes | ||||||||
| 4 [100] and under |
40 | 0 | 35 | 0 | 33 | 0 | 28 | 0 |
| Over 4 [100] | .... | .... | 35 | 0 | 33 | 0 | 28 | 0 |
| Seamless, Cold-Finished Tubes | ||||||||
| Over | Under | |||||||
| 1 1 ⁄ 2 [38.1] and under | 20 | 0 | ||||||
| Over 1 1 ⁄ 2 [38.1] | 22 | 0 | ||||||
