Stainless Steel Pipe 304/304L is a tubular shaped 304/304L Stainless Steel Alloy pipe.
304/304L Stainless Steel Alloy has excellent mechanical properties and is resistant to many corrosive agents.
It is useful where sanitation and cleanliness are important. Non magnetic in the annealed condition. Hardness and tensile strength can be increased by cold working, but modified by lowered carbon content providing good resistance to corrosion in welded construction where subsequent heat treatment is not practical.
Grade 304L (L= low carbon) is the same as the 304 except it has an extra-low-carbon analysis, the advantage of which is that it precludes any harmful precipitation in the 800º F to 1500º F range, such as might otherwise occur in welding heavier sections. Specifications
EN 10088-3, 1.4301 Characteristics
Cold Working: Good
Corrosion Resistance: Excellent
Heat Resistance: Good
Heat Treatment: Poor
Hot Working: Fair
Machinability: Good
Weldability: Very Good Uses
Common uses of Stainless Steel Pipe 304/304L include:
Architectural Paneling
Bolts
Cutlery & Flatware
Food & Pharmaceutical Production Equipment
Nuts
Sanitary Ware & Troughs
Saucepans
Screws
Sinks & Splash Backs
Springs More Info
Density: 8.00 g/cm³
Electrical Resistivity: 0.72 x10^-6 Ω .m
Elongation A50 mm: 45 Min %
Hardness Brinell: 215 Max HB
Melting Point: 1450 °C
Modulus of Elasticity: 193 GPa
Proof Stress: 190 Min MPa
Tensile Strength: 500 – 700 MPa
Thermal Conductivity: 16.2 W/m.K
Thermal Expansion: 17.2 x10^-6 /K
Chemical Requirements
| Grade A | Grade B | Grade C | |
| Carbon max. % | 0.25 | 0.30* | 0.35* |
| *Manganese % | 0.27 to 0.93 | *0.29 to 1.06 | *0.29 to 1.06 |
| Phosphorous, max. % | 0.035 | 0.035 | 0.035 |
| Sulfur, max. % | 0.035 | 0.035 | 0.035 |
| Silicon, min.% | 0.10 | 0.10 | 0.10 |
| Chrome, max. % | 0.40 | 0.40 | 0.40 |
| Copper, max. % | 0.40 | 0.40 | 0.40 |
