Alloy 316/316L performs well in fresh water service even with high levels of chlorides. The alloy has excellent resistance to corrosion in marine environments under atmospheric conditions.
Chemical Analysis
| Element | 316 | 316L |
| Chromium | 16.0 min.-18.0 max. | 16.0 min.-18.0 max. |
| Nickel | 10.0 min.-14.0 max. | 10.0 min.-14.0 max. |
| Molybdenum | 2.00 min.-3.00 max. | 2.00 min.-3.00 max. |
| Carbon | 0.08 | 0.030 |
| Manganese | 2.00 | 2.00 |
| Phosphorus | 0.045 | 0.045 |
| Sulfer | 0.03 | 0.03 |
| Silicon | 0.75 | 0.75 |
| Nitrogen | 0.1 | 0.1 |
| Iron | Balance | Balance |
Stainless steel coils surface finish characteristics
|
Surface finish |
Characteristics and application |
||
|
2B |
The surface brightness and flatness of no2B is better than no2D. |
||
|
NO.1 |
Polished with abrasive belt of grit#100-#200, have better brightness with discontinuous coarse stria, |
||
|
NO.4 |
Polished with abrasive belt of grit #150-#180,have better brightness with discontinuous coarse stria, |
||
|
HL |
Polished with abrasive belt of grit #150-#320 on the NO.4 finish and has continuous streaks, |
||
|
BA |
Cold rolled, bright annealed and skin-passed, |
||
|
8K |
The product have excellent brightness and prefer reflexivity can to be the mirror. |
||
Does stainless steel rust?
Equivalent to Grade SUS316L in the annealed condition, and superior if a weldment in these grades has not been post-weld annealed or if the application involves service in the 425-900°C range. Subject to pitting and crevice corrosion in warm chloride environments, and to stress corrosion cracking above about 60°C. Considered resistant to potable water with up to about 200mg/L chlorides at ambient temperatures, reducing to about 150mg/L at 60°C.
