An enquiry that lists DX51D, Z180, DC01, G90 and Z275 together is mixing three different naming systems, and the first task is to untangle them. DX51D and DC01 describe the steel substrate, Z180 and Z275 are European-style coating mass codes, and G90 is the American coating weight equivalent of Z275. This article explains each element, shows how the codes convert, and sets out how to specify a galvanized steel coil order so that the mill, the fabricator and the end user all mean the same thing.
Coating Mass Codes and How They Convert
Coating mass is the most useful durability statement on a galvanized coil order. European and Chinese practice states the total zinc mass applied to both surfaces, so Z275 means 275 g/m2 in total, which is about 137.5 g/m2 per side. American practice states the same total in ounces per square foot, and because one ounce per square foot equals about 305 g/m2, the familiar conversions follow.
| EN coating code | Total mass, both sides | Mass per side | Thickness per side | US G code |
| Z100 | 100 g/m2 | 50 g/m2 | about 7 micrometres | G30 |
| Z180 | 180 g/m2 | 90 g/m2 | about 13 micrometres | G60 |
| Z275 | 275 g/m2 | 137.5 g/m2 | about 19 micrometres | G90 |
Thickness values are derived from the density of zinc, 7.14 g/cm3, so a coating mass of 90 g/m2 per side corresponds to roughly 13 micrometres of zinc. Zinc protects steel sacrificially, which means small scratches, drilled holes and cut edges remain protected by the surrounding coating instead of rusting immediately, and that is the practical reason a heavier coating buys a longer service life.
Substrate Codes: DX51D and DC01
The two substrate codes come from different standards and describe different stages of the same production route. DC01 is a cold-rolled low-carbon steel for cold forming defined in EN 10130, with no coating. DX51D is the continuously hot-dip coated forming grade defined in BS EN 10346:2015, where the substrate is a comparable low-carbon cold-rolled steel that has then been passed through the zinc bath.
In everyday commercial language DC01 is therefore the base metal and DX51D is the coated product. A coil described as DX51D Z275 will typically sit on a substrate of DC01 or SPCC character, and a supplier may mention DC01 explicitly to show that the base metal is a standard cold-rolled grade rather than a re-rolled or non-prime material. When both codes appear on one enquiry, the sensible reading is that the buyer wants a galvanized DX51D coil whose substrate is a DC01-equivalent cold-rolled steel.
Reference Specification for a Galvanized Coil Order
| Item | Typical value |
| Steel grade | DX51D, coated forming grade; DC01 or SPCC equivalent substrate |
| Standards | BS EN 10346:2015; DC01 substrate to EN 10130; SGCC to JIS G 3302 as an alternative |
| Thickness range | 0.12 to 4.0 mm, with 0.3 to 2.0 mm the most common band |
| Coating | Z100, Z180, Z275 in total on both sides, or the matching G30, G60, G90 codes |
| Mechanical properties | yield strength about 140 to 280 MPa, tensile strength about 270 to 500 MPa, elongation 22 percent minimum |
| Surface | regular or minimised spangle, skin pass, chromate-free passivation, optional oiling |
| Supply form | coil with 508 mm or 610 mm inner diameter, or cut to length sheet and slit strip |
Choosing Between Z180 and Z275
Z180 is the usual choice for ordinary building components, ventilation equipment, cable trays and general fabrication that faces weather but not severe chemistry.
Z275 is specified for fully exposed roofing and cladding, coastal or humid sites, and any part where a long interval between maintenance cycles matters.
Z100 remains appropriate for dry indoor parts and for painted components where the paint supplies most of the barrier protection.
Where high temperature, high humidity or salt exposure is combined, an aluminium-zinc coating such as AZ150, with about 55 percent aluminium, 43.4 percent zinc and 1.6 percent silicon, is often a better answer than a heavier pure zinc layer.
Forming, Welding and Handling Notes
DX51D has good ductility and is suitable for bending, profiling, lock forming and moderate drawing; the practical forming limit depends on tool radii, lubricant and blank edge quality.
Resistance spot welding is the standard joining method; zinc raises contact resistance and reduces electrode life, so increase electrode force, shorten weld time and dress electrodes regularly.
Cut edges and drilled holes are protected sacrificially, but a heavily torn edge can still become the first rust site, so keep slitting and shearing tooling sharp.
Store coils dry and ventilated with a slight incline so condensation drains, and use lifting equipment that supports the full coil width.
Painted or powder coated parts need degreasing and a phosphate or equivalent conversion pretreatment, since zinc surfaces are not paint-ready as supplied.
Frequently Asked Questions
Q: Is Z275 the same as G90?
They express the same coating weight in different systems. G90 means 0.90 ounces per square foot measured on both sides combined, which converts to about 275 g/m2, so G90 is the American equivalent of the European code Z275. Both correspond to roughly 137.5 g/m2 or 19 micrometres of zinc per side.
Q: What is Z180 material?
Z180 indicates a zinc coating of 180 g/m2 in total on both sides, about 90 g/m2 or 13 micrometres per side, and it is close to the G60 code. It is a common specification for building components that face normal outdoor weather and is lighter and cheaper than Z275.
Q: What is the difference between DX51D and DX52D?
Both are coated forming grades to BS EN 10346:2015, but DX52D has higher ductility and better elongation than DX51D. DX52D is chosen for forming operations that need greater flexibility, while DX51D covers standard bending, profiling and moderate drawing work.
Q: What is DX51D material equivalent to?
The principal cross references are SGCC to JIS G 3302 and DC51D+Z to GB/T 2518. All three are commercial-quality hot-dip galvanized forming grades on a low-carbon substrate, though each standard writes its mechanical property limits and coating tolerances in its own way.
Q: What is DC01 base steel?
DC01 is a cold-rolled low-carbon steel for cold forming defined in EN 10130, supplied uncoated. It is soft, formable and dimensionally consistent, which makes it the natural substrate for subsequent hot-dip galvanizing, and its SPCC counterpart in JIS G 3141 plays the same role in the Japanese system.
Q: What is an AZ150 coating and when should it be selected?
AZ150 is an aluminium-zinc coating of 150 g/m2 in total on both sides, made up of roughly 55 percent aluminium, 43.4 percent zinc and 1.6 percent silicon. It offers strong heat and corrosion resistance in hot, humid or salt-laden conditions, and it is normally preferred over pure zinc when the environment is aggressive and welding is not required.
