What is SGCC material?
SGCC refers to steel sheets that have been subjected to hot-dip galvanisation. In English, it is abbreviated as "Steel Galvanised Cold Commercial." Since hot-dip galvanisation is applied to SPCC material, its basic properties are similar to those of SPCC.
What is the difference between DX51D and DC51D?
DX51D vs DC51D
DX51D uses the same level as DC01 when the base plate is cold-rolled, and the same level as DD11 when it is hot. DC51D substrate is DC01 cold rolled low carbon steel plate.
What does GI mean galvanised?
The word GI means "Galvanized Steel", is the most economical and effective coated steel product with application of Zn coating (known as Galvanizing process) that provides proper steel corrosion protection.
How to calculate zinc coating thickness?
The density of the zinc is 7.14. Therefore, a thickness of 1 micron of zinc is equivalent to 7.14 g/m2. Example: zinc coating thickness measured on one side of the CGI sheet is 20 µm. Then, the zinc coating mass is equal to: 20 x 7.14 = 135.66 g/m2 of zinc on one side.
What is Dx51d AZ150 material?
Dx51d AZ150 is a hot-dip aluminum-zinc steel alloy with a coating of 55 percent aluminum, 1.6 percent silicon, and 43.4 percent zinc. The chemical composition of Dx51d AZ150 offers superior resistance to heat and corrosion, with high thermal reflectivity and conductivity.
