Cold-Rolled Grade Families: JIS SPCC Series and EN DC Series

Jun 12, 2025 Leave a message

Every cold-rolled steel order begins with a grade name, and in international trade the name comes from one of two ladders: JIS G3141 (SPCC, SPCD, SPCE, SPCF, SPCG) or EN 10130 (DC01 to DC06). The two systems rank the same property, formability, and they map onto each other almost step by step. Understanding the ladder prevents both over-specification and the cracking that comes from under-specification.

The JIS Family: SPCC to SPCG

Grade Forming level Carbon, max
SPCC Commercial; bending and simple stamping 0.12%
SPCD Drawing; medium stamping 0.10%
SPCE Deep drawing; complex forming 0.08%
SPCF Extra deep drawing 0.06%
SPCG Super deep drawing 0.02%

Each step lowers the carbon limit and raises the guaranteed elongation, so the family covers everything from flat brackets to the most demanding deep-drawn panels.

The EN Family: DC01 to DC06

Grade Forming level Carbon, max Elongation A80
DC01 Bending, embossing, shallow stamping 0.12% Min 28%
DC03 Drawing, difficult profiling 0.10% Min 34%
DC04 Deep drawing, high forming requirements 0.08% Min 38%
DC05 Higher forming requirements 0.06% Min 40%
DC06 Highest forming requirements (IF steel) 0.02% Min 40%

The two ladders align: SPCC/DC01, SPCD/DC03, SPCE/DC04, SPCF/DC05, SPCG/DC06. They are functional equivalents, not identical grades, and the certificate must state the governing standard.

DC04 versus DC05 and DC06

DC04 handles high forming requirements and is the standard deep-drawing grade for parts such as drawn housings and automotive fuel tanks. DC05 raises the guarantee to 40% elongation for higher forming requirements, and DC06, an interstitial-free steel, delivers the highest deep-drawing capability with very low carbon. The premium for DC06 is justified only when the drawing ratio truly exceeds DC04 or DC05; otherwise the extra cost buys unused capability.

DC01 versus DC04

DC04 has significantly better formability than DC01: it withstands complex shaping and deep drawing without cracking, while DC01 is ideal for simple forming such as bending, shallow drawing and light stamping. The price difference between them is modest relative to the cost of a cracked die or a scrapped batch, so when the drawing is borderline, moving up one grade is usually the economical decision.

Why Is Cold-Rolled Steel Stronger?

Cold rolling deforms the steel at room temperature, which increases hardness, tensile resistance and deformation resistance through work hardening. The same chemistry that yields about 270-410 MPa tensile in annealed DC01 behaves stronger and harder in the cold-rolled condition. That strength is useful in flat parts but reduces formability, which is why most cold-rolled coil is supplied annealed and skin-passed, restoring ductility while keeping the smooth surface and tight tolerances.

Frequently Asked Questions

1. What is the difference between SPCC and SPCE?

SPCC is the commercial grade for bending and simple stamping; SPCE is the deep-drawing grade with lower carbon and higher elongation. Move up the ladder as the drawing ratio increases.

2. Can DC01 be deep drawn?

Only shallow drawing. For deep drawing specify DC03 or DC04; DC05 and DC06 cover the highest deformation demands.

3. Which standard should my order follow?

Use the standard the customer's drawing specifies: JIS G3141 in Japanese and many Asian markets, EN 10130 in Europe and most export projects. Mixing designations on the certificate creates inspection problems.

4. Is SPCF the same as DC05?

Functionally yes, both are extra-deep-drawing grades with about 0.06% carbon, but they are defined in different standards with different testing rules and certified documents.

5. What does CRC mean?

CRC stands for cold-rolled coil (or cold-reduced coil), a process description, not a grade. Always pair it with a grade name such as SPCC or DC01 on the order.

6. Why does my cold-rolled coil show a dull surface?

A matte finish is normal on skin-passed material intended for painting; bright finishes are produced by additional processing. Specify the surface requirement if the finish matters to the application.
