Products Description
GNEE STEEL color coated steel coil is a high-quality product that combines the strength and durability of steel with the aesthetic appeal of a colorful coating. It is manufactured through a precise process that involves cleaning, pretreatment, coating, and curing of the steel substrate. The result is a steel plate with excellent corrosion resistance, weatherability, and a smooth, uniform surface finish.
- Color Coated Coil:
Production thickness:0.2mm - 1.2mm, Width: 750mm - 1250mm, Dry film thickness per side: 15μm - 40μm.
High Weathering Resistance (HWR),Fluorocarbon (PVDF),Silicone-modified Polyester (SMP), Two-coat Two-bake Process, Laminated, Embossed,Suede finish
| tem | Details |
| Base Material | High-quality cold-rolled steel, hot-dip galvanized steel, galvalume steel |
| Coating Type | Polyester (PE), Silicon Modified Polyester (SMP), Polyvinylidene Fluoride (PVDF), Plastisol |
| Coating Thickness | Typically ranging from 15μm to 25μm for single-side coating, customized according to requirements |
| Steel Thickness | 0.12mm - 2.0mm |
| Width | 700mm - 1500mm |
| Length | Customizable according to customer needs |
| Color Options | A wide range of standard colors (such as red, blue, green, gray, white) and can also be customized |
Advantages
| Superior Corrosion Resistance | The coating acts as a protective barrier, effectively preventing the steel from rusting and corroding, even in harsh environments such as coastal areas or industrial zones with high humidity and pollutants. |
| Excellent Weatherability | It can withstand various weather conditions, including strong sunlight, heavy rain, snow, and extreme temperatures. The color and coating properties remain stable over a long period, reducing the need for frequent maintenance and replacement. |
| Aesthetic Appeal | With a diverse range of colors and finishes available, our color coated steel plate can enhance the visual appearance of buildings and structures. It can be used to create modern, stylish, and eye-catching designs. |
Packaging and Shipping
application scenarios
| Building Construction | Widely used for roofing, wall cladding, and interior partitions in industrial buildings, commercial buildings, warehouses, and residential houses. It provides a durable and attractive exterior while also offering good thermal insulation and soundproofing properties. |
| Home Appliances | Applied in the manufacturing of refrigerators, washing machines, air conditioners, and other home appliances. The color coated steel plate not only gives the appliances an appealing appearance but also protects them from scratches and corrosion. |
| Transportation Industry | Used in the production of truck bodies, trailers, containers, and railway carriages. Its lightweight and high strength characteristics help to improve fuel efficiency and reduce transportation costs. |
GNEE STEEL's qualifications
GNEE STEEL participated in the exhibition
