Hot Dip Aluminium-zinc Alloy Coating Steel S220GD+AZ

S220GD refers to hot-dip coated structural steel grade with specified minimum yield strength of 220MPa, dedicated for forming and structural use.+AZ represents classic galvalume coating with standardized composition: 55% Aluminum + 43.4% Zinc + 1.6% Silicon.Different from deep drawing series steel, S220GD+AZ focuses on high structural strength and comprehensive weather resistance, balancing mechanical property, coating protection and economic cost. The compact alloy coating forms dual barrier and sacrificial anti-corrosion protection, with better high temperature resistance, heat reflection and surface stability than traditional hot dipped galvanized steel.

S220GD+AZ Galvalume Steel Coil is a hot-dip 55% aluminum-zinc-silicon alloy coated structural steel coil, featured with stable yield strength, excellent structural rigidity, outstanding atmospheric corrosion resistance and good bending & forming performance. As a mainstream structural-grade galvalume steel material, it perfectly solving customers' worries about structural load-bearing, outdoor rusting, short service life and unstable processing quality. It is the preferred raw material for construction, engineering structures, transportation and general industrial manufacturing.

*According to EN 10346-2015.

*The following minimum elongation values apply for different thicknesses:

0.5mm < t ≤ 0.7mm: minimum elongation is reduced by 2% from the values in the table.

0.35mm < t ≤ 0.5mm: minimum elongation is reduced by 4% from the values in the table.

t ≤ 0.35mm: minimum elongation is reduced by 7% from the values in the table.

Construction industry: Metal roof, wall panel, purlin, warehouse enclosure, light steel structure accessories

General industry: Equipment shell, ventilation duct, storage shelf, factory profile

Transportation: Vehicle compartment board, logistics equipment structural parts

New energy: Solar support accessories, environmental protection equipment shell

Deep processing: Raw material for PPGL color coated steel, stamped and profiled parts

Q1: What does S220GD+AZ mean?

A1: S220GD is structural hot-dip coated steel grade with 220MPa minimum yield strength; +AZ refers to 55% aluminum-zinc-silicon galvalume protective coating.

Q2: What is the difference between S220GD+AZ and deep drawing grade DC series galvalume?

A2: S220GD focuses on structural strength and load-bearing performance, more suitable for building and engineering structural parts; DC series is for complex deep drawing and stamping processing.

Q3: How to choose among AZ150, AZ180 and AZ200?

A3: Inland dry areas choose AZ150 for cost saving; humid and urban industrial areas choose AZ180; coastal and heavily polluted industrial areas prioritize AZ200.

Q4: Can S220GD+AZ be used for outdoor long-term exposure?

A4: Yes, all three coating weights are applicable to outdoor use. Thick coating AZ200 is highly recommended for high corrosion areas.

Q5: What size specifications can be customized?

A5: Conventional thickness 0.2–2.0mm, width 600–1500mm, coil weight and inner diameter can be customized according to demand.

Q6: Is surface treatment available for options?

A6: Multiple treatments are optional: anti-fingerprint, chromated passivation, non-chromate treatment, oiled or dry surface.

Q7: Can you provide official test reports?

A7: Yes, factory factory test certificate is provided, and SGS, BV, TÜV third-party inspection can be supported.

Q8: Is galvalume coil environmentally friendly and recyclable?

A8: The whole material is recyclable, with low environmental impact, meeting global environmental protection and green building material standards.
